Is there any way of using entire latex syntax inside TiddyWiki?

muynars...@gmail.com

unread,

May 2, 2021, 6:25:51 PM5/2/21

to TiddlyWiki

I know that with the KaTex Plugin I can partially use LaTex syntax by adding $$ at the beginning of the phrase like:

$$\displaystyle f(x) = \int_{-\infty}^\infty\hat f(\xi)\,e^{2 \pi i \xi x}\,d\xi$$

However, I'd like to put the entire LaTex syntax on my tiddlers like the following:

```latex

% Pie chart
% Author: Robert Vollmert
\documentclass{article}

\usepackage{calc}
\usepackage{ifthen}
\usepackage{tikz}
\begin{document}
\newcommand{\slice}[4]{
\pgfmathparse{0.5*#1+0.5*#2}
\let\midangle\pgfmathresult

% slice
\draw[thick,fill=black!10] (0,0) -- (#1:1) arc (#1:#2:1) -- cycle;

% outer label
\node[label=\midangle:#4] at (\midangle:1) {};

% inner label
\pgfmathparse{min((#2-#1-10)/110*(-0.3),0)}
\let\temp\pgfmathresult
\pgfmathparse{max(\temp,-0.5) + 0.8}
\let\innerpos\pgfmathresult
\node at (\midangle:\innerpos) {#3};
}

\begin{tikzpicture}[scale=3]

\newcounter{a}
\newcounter{b}
\foreach \p/\t in {20/type A, 4/type B, 11/type C,
                   49/type D, 16/other}
{
    \setcounter{a}{\value{b}}
    \addtocounter{b}{\p}
    \slice{\thea/100*360}
          {\theb/100*360}
          {\p\%}{\t}
}

\end{tikzpicture}

\end{document}

```

This is a pie chart made in LaTex language. Is there any way of making TiddlyWiki show the result of what I write like that? Just by using the same syntax that I use for choosing syntax? Or is there an alternative way to reach this same goal?

Ste

unread,

May 2, 2021, 7:19:31 PM5/2/21

to TiddlyWiki

Hi,

I think the short answer is no. :(

Katex supports a lot of LaTeX https://katex.org/docs/supported.html

But I don't think ticz drawings are supported.

Im still kinda hoping https://github.com/pyramation/LaTeX2JS

takes goes viral and some mad genius makes a plugin out of it :)

Maybe next it will week when I win the lotto! :)
I have used that with a free Dropbox hosting and Iframed it into a tiddlywiki.

There are other diagramming plugins available for tiddlywiki.

Have a search in the community vault:

https://links.tiddlywiki.com/

Anjar

unread,

May 2, 2021, 7:24:52 PM5/2/21

to TiddlyWiki

Hi,

I don't think there is any way to render a full latex document by javascript (or is there? https://github.com/kisonecat/web2js); you may have to actually run latex somehow, for example through php: https://github.com/scarfboy/phplatex There is a js library for rendering tikz that may be useful https://github.com/kisonecat/tikzjax

If making charts is more important than using latex, you can have a look at this short thread about Charts.css (although pie charts are not currently supported)

Best,

Anders

muynars...@gmail.com

unread,

May 2, 2021, 10:17:18 PM5/2/21

to TiddlyWiki

Thanks everyone for the answers,

I'm checking the links... I really liked the interactivity that the https://github.com/pyramation/LaTeX2JS plugin allows us to do. I've tried making a fast adaption here using a tiddler of type html but it doesn't work. I don't know why, if I save a file with the following content on my computer as html and open it with a browser it works:

<!DOCTYPE html>

<head>

<title>LaTeX2JS Examples</title>

</head>

<body>

<h1>LaTeX2JS Examples</h1>

</div>

<br>

\begin{pspicture}(0,-3)(8,3)

\rput(0,0){$x(t)$}

\rput(4,1.5){$f(t)$}

\rput(4,-1.5){$g(t)$}

\rput(8.2,0){$y(t)$}

\rput(1.5,-2){$h(t)$}

\psframe(1,-2.5)(7,2.5)

\psframe(3,1)(5,2)

\psframe(3,-1)(5,-2)

\rput(4,0){$X_k = \frac{1}{p} \sum \limits_{n=\langle p\rangle}x(n)e^{-ik\omega_0n}$}

\psline{->}(0.5,0)(1.5,0)

\psline{->}(1.5,1.5)(3,1.5)

\psline{->}(1.5,-1.5)(3,-1.5)

\psline{->}(6.5,1.5)(6.5,0.25)

\psline{->}(6.5,-1.5)(6.5,-0.25)

\psline{->}(6.75,0)(7.75,0)

\psline(1.5,-1.5)(1.5,1.5)

\psline(5,1.5)(6.5,1.5)

\psline(5,-1.5)(6.5,-1.5)

\psline(6,-1.5)(6.5,-1.5)

\pscircle(6.5,0){0.25}

\psline(6.25,0)(6.75,0)

\psline(6.5,0.5)(6.5,-0.5)

\end{pspicture}

<br>

<hr>

<br>

\begin{pspicture}(-2,-2)(2,2)

\psframe(-2,-2)(2,2)

\userline[linewidth=1.5 pt]{->}(0,0)(2,2)

\end{pspicture}

<hr>

</script>

LaTeX2HTML5.init();

</script>

</body>

</html>

I got it from the page https://latex2js.com/examples/index.html and just changed the relative paths to absolute paths... But well, inside TiddlyWiki it doesn't work as a type HTML, does anyone know why? Does the HTML type of tiddlers work exactly as an HTML file?

PMario

unread,

May 3, 2021, 7:53:10 AM5/3/21

to TiddlyWiki

On Monday, May 3, 2021 at 1:24:52 AM UTC+2 Anjar wrote:

...

I don't think there is any way to render a full latex document by javascript (or is there? https://github.com/kisonecat/web2js); you may have to actually run latex somehow,

Very interesting project. It seems to run a full blown TeX ... not LaTeX environment in the browser.

In the background it needs about 13 MByte of WASM code + TeX configuration to + editor ...

But it seems, that it still needs a backend to load assets like fonts ... As far as I can see, inspecting the live demo code. ..

So there would be some considerable work to do, to slim the stuff down to make it usable with TW.

-mario
