Training doesn´t work 3.02 (Commandcorrection??)

[Awsomo :(]

Hi,

I have installed Tesseract v3.02 with Cowboxer as Boxtool on Win7 x64bit,

i´ve allready created a Boxfile from a tiff witch are both have the same name and are laydowned in the same Folder named Tessdata.

The main Problem i have now is that Tesseract reports that it cannot open the input file.

this are the two commands i use:

tesseract deu.handwriting.exp0.tif deu.handwriting.exp0] box.train

tesseract [deu].[handwriting].exp[0].tif [deu].[handwriting].exp[0] box.train.stderr

https://code.google.com/p/tesseract-ocr/wiki/TrainingTesseract3#How_little_can_you_get_away_with

this is really a mess and hard to understand with my english knowlege.

What did i do wrong?

If anybody can give more information for Training of Tesseract 3.02

,would be really awesome.

[Quan Nguyen]

The commands should be:



tesseract deu.handwriting.exp0.tif deu.handwriting.exp0 box.train



or



tesseract deu.handwriting.exp0.tif deu.handwriting.exp0 box.train.stderr

[Awsomo :(]

"The commands should be:



tesseract deu.handwriting.exp0.tif deu.handwriting.exp0 box.train



or



tesseract deu.handwriting.exp0.tif deu.handwriting.exp0 box.train.stderr"

Thank you i tried ,  but it still reprots the message:

-->Tesseract Open Source OCR Engine v3.02 with Leptonica

Cannot open input file: deu.handwriting.exp0.tif<--

I have tried it with the files in this folder "tesseract-OCR\Tessdata" and on the  "Desktop \Tessdata" after deleting them from the other.

C:\Program Files\Tesseract-OCR\Tessdata>tesseract deu.handwriting.exp0.tif deu.handwri

ting.exp0 box.train.stderr

Tesseract Open Source OCR Engine v3.02 with Leptonica

Cannot open input file: deu.handwriting.exp0.tif

C:\Program Files (x86)\Tesseract-OCR\tessdata>tesseract deu.handwriting.exp0.ti

 deu.handwriting.exp0 box.train

Tesseract Open Source OCR Engine v3.02 with Leptonica

Cannot open input file: deu.handwriting.exp0.tif

also all types of renaming the box.and.tif Files like :

this

deu.handwriting.exp0.tif

deu.handwriting.exp0.box

or

handwriting.exp0.tif

handwriting.exp0.box

or this like i first supposed the name should be..

exp0.tif

exp0.box

because i couldn´t find more information about the designation of the tiff and box files.

Are there any steps to do before, i might could miss?

[Nick White]

On Wed, Apr 23, 2014 at 09:57:35AM -0700, Awsomo :( wrote:
> Thank you i tried , but it still reprots the message:
>
> -->Tesseract Open Source OCR Engine v3.02 with Leptonica
> Cannot open input file: deu.handwriting.exp0.tif<--

That error message is printed because it can't find that file. So
either it isn't named correctly, or it isn't in the directory you're
running it from.

Actually it also may be possible that the TIFF isn't valid; can you
upload a copy to compare against? Or just convert it to a PNG and
try that (replacing .tif with .png).

Nick

[Awsomo :(]

Hi Nick, i tried all combinations of the name but i don´t really know what the exact name of the file should be,



    here are the files.

I used that path to my directory C:/User/alias/program files (x86)/Tesseract-OCR/Tessdata.





[Nick White]

On Thu, Apr 24, 2014 at 06:41:04AM -0700, Awsomo :( wrote:
> Hi Nick, i tried all combinations of the name but i don´t really know what
> the exact name of the file should be,

OK, I see, in your case the exact name of the .tif file should be:
deu.handwriting.exp0.tif

And the .box file should be named:
deu.handwriting.exp0.box

The .tif looks fine, by the way, Tesseract can read it without
issues, so once you name the files properly all should be well.

Nick

[Awsomo :(]

Thank you. That worked out so far,.  :)

-no report the

-picture opens up after exicuting the command

but

no fontfile.tr

that should be generated in this step, i think.

Is the tr.file generated in a lib_folder or

do i have to use one of the option for Pagemodus maybe  to make a better

and if thats so what is the syntaxs for that.



pagesegmode values are:

0 = Orientation and script detection (OSD) only.

1 = Automatic page segmentation with OSD.

2 = Automatic page segmentation, but no OSD, or OCR

3 = Fully automatic page segmentation, but no OSD. (Default)

4 = Assume a single column of text of variable sizes.

5 = Assume a single uniform block of vertically aligned text.

6 = Assume a single uniform block of text.

7 = Treat the image as a single text line.

8 = Treat the image as a single word.

9 = Treat the image as a single word in a circle.

10 = Treat the image as a single character.

-l lang and/or -psm pagesegmode must occur before anyconfigfile.

I tried it like that..

C:\Users\alias\Desktop\Tessdata>tesseract deu.handwriting.exp0.tif deu.handwri

ting.exp0 box.train 3

read_params_file: Can't open 3

Tesseract Open Source OCR Engine v3.02 with Leptonica

FAIL!

APPLY_BOXES: boxfile line 0/4 ((83,3290),(162,3445)): FAILURE! Couldn't find a m

atching blob

FAIL!

APPLY_BOXES: boxfile line 1/5 ((242,3302),(338,3457)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 2/6 ((384,3302),(480,3457)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 3/7 ((565,3306),(661,3461)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 4/8 ((702,3312),(798,3451)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 5/9 ((854,3312),(950,3451)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 6/0 ((986,3312),(1086,3451)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 7/1 ((1151,3312),(1219,3451)): FAILURE! Couldn't find

a matching blob

FAIL!

APPLY_BOXES: boxfile line 8/2 ((1272,3312),(1356,3451)): FAILURE! Couldn't find

a matching blob

FAIL!

APPLY_BOXES: boxfile line 9/3 ((1421,3324),(1505,3463)): FAILURE! Couldn't find

a matching blob

FAIL!

APPLY_BOXES: boxfile line 10/3 ((1409,3130),(1493,3269)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 11/2 ((1265,3126),(1349,3265)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 12/1 ((1133,3118),(1217,3257)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 13/0 ((973,3118),(1081,3257)): FAILURE! Couldn't find

a matching blob

FAIL!

APPLY_BOXES: boxfile line 14/9 ((868,3104),(936,3251)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 15/8 ((716,3104),(788,3259)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 16/7 ((558,3104),(638,3259)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 17/6 ((399,3115),(487,3270)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 18/5 ((263,3115),(351,3270)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 19/4 ((79,3091),(167,3246)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 20/4 ((79,2843),(167,3010)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 21/5 ((243,2845),(347,3040)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 22/6 ((375,2860),(479,3039)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 23/7 ((527,2888),(631,3067)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 24/8 ((703,2900),(791,3067)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 25/9 ((855,2904),(943,3071)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 26/0 ((975,2918),(1067,3057)): FAILURE! Couldn't find

a matching blob

FAIL!

APPLY_BOXES: boxfile line 27/1 ((1131,2929),(1179,3052)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 28/2 ((1244,2932),(1320,3059)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 29/3 ((1398,2948),(1478,3079)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 30/3 ((1382,2707),(1478,2874)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 31/2 ((1250,2699),(1350,2850)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 32/1 ((1164,2688),(1204,2843)): FAILURE! Couldn't find

 a matching blob

FAIL!

APPLY_BOXES: boxfile line 33/0 ((988,2708),(1112,2871)): FAILURE! Couldn't find

a matching blob

FAIL!

APPLY_BOXES: boxfile line 34/9 ((844,2692),(956,2855)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 35/8 ((691,2668),(803,2831)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 36/7 ((529,2646),(629,2797)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 37/6 ((373,2614),(473,2781)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 38/5 ((220,2598),(320,2765)): FAILURE! Couldn't find a

 matching blob

FAIL!

APPLY_BOXES: boxfile line 39/4 ((64,2598),(164,2765)): FAILURE! Couldn't find a

matching blob

FAIL!

APPLY_BOXES: boxfile line 40/A ((0,3508),(-1,3507)): FAILURE! Couldn't find a ma

tching blob

APPLY_BOXES:

   Boxes read from boxfile:      41

   Boxes failed resegmentation:      41

APPLY_BOXES: Unlabelled word at :Bounding box=(-1501,-889)->(-75,-23)

   Found 0 good blobs.

   1 remaining unlabelled words deleted.

Generated training data for 0 words

[Awsomo :(]

ok, there was a problem with the Picture i used, tesseract couldn´t use it because of the size i think.

However now its working and generating the requested TR.Files to.

Thanks to everybody who helped me to fix this problems so far.!
