Posted: 09 Feb 2021 10:35 AM PST Recently I had the idea to improve the possibility to quick measure the frequency difference of two reference oscillators , in this case two Rubidium Oscillators : a Rhode Schwarz and an M100 that I put into a yellow rack with a power supply , as in the pictures .  A) Multiplying by 100 the frequency of both oscillators ( with the use of simple home made Comb Generators ) B) Comparing the frequency of the two oscillators with the method of the " beats " at 1 GHz , using a selective receiver . In the test I have used a Spectrum Analyzer , but every simple receiver , even an RTL Dongle can be used with the same results . The two Comb Generator needed was made with two EX-OR fast ports ( ACT86) , with one of the two inputs connected directly and the second through a variable resistor that , with the input capacitor of the port ,add a small delay .  Trimming the resistor the component at 1 GHz was at a comfortably level of -50 dBm . The output of the two Comb generator was summed simply with two capacitor and two resistors . You can find here the images of the output of a single Comb Generator , wide band and relatively narrow band .   What can we espect from this setup while
summing the signal of the two Comb Generator at 1
GHz coming from the two Rubidium ?
The composition of the two signals will
change from a maximum of +3 dB when the phase of the
two oscillator is the same and to a minimum ( if the
signals are exactly equal of ) zero .
In this case the spream is around 20 dB , but
doesn't mattere because we have only to count the
cycles .
The maximums will be always very wide , while
the nulls will be always very sharp .
To check this I have tuned the Rubidium M100
as far as was possible , and you can see in the
first part of the following screen with zero span (
this means that the Spectrum Analyzer acts as a
receiver tuned at 1 GHz with vertical logaritmic
scale ) .
Please note that the horizontal time sweep is
1000 s ( 100 second/div) .
At the beginning you can count around 10
oscillations in 100s , that means one cicle each 10
seconsd = 0,1 Hz of difference at 1 GHz .
Being 1 GHz = 10E9 Hz , this means a
frequency maximun difference of 10E-10 .
While time was running , I have changed the
frequency of the Rubidium M100 to approach that one
of the RS Rubidium .
At the end of the screen the difference is
around one cycle each ten second at 1 GHz , that
means 10E-11.
 Continuing the approach of the frequencies ,
I have increased the timebase till 6000 s because
the phase change was very slow .
 At the end , using sequential methof of
approcimation , in the last picture ,it is not easy
if impossible to see a real periodicity in the phase
rotation and so in the frequency difference .
We are in the range of 10E-12 . I am pretty
sure that this limit doesn't depend from the method
of measurement ( being a "physical method ") , but
from the limit of stability ( jitter ) of one ( if
not both ) Rubidium Oscillator , and this was the
scope of the experiment .
If I am right , this simple setup , that
everyone can easily reproduce at low cost , can
measure stability higher than that of Rubidium
Oscillators .
To check this with no dubts , I need two
oscillator with performance 10 times better than the
rubidium oscilllator I have used .
Hope one day I can check this , if I am so
crazy to invest in two Masers , because actually I
am only playing to infringe my limits .....
But I have another couple of Rubidium
Oscillators from Stanford that I can try to check
in the same way ....
 |
|
